Description：

Primary Voltage Ratings: 34.5-19.92/13.8-7.957/13.2-7.62/12.47-7.2, 13.2, 44, or others
Secondary Voltage Ratings: 208GrdY/120; 416GrdY/240, 480GrdY/277, 600GrdY/347, 220y/127, 480V, 415V, 600V, or others
High Voltage Tap Range: ±2×2.5% or others
Connection Types: Dyn11/YNyn0 or others
Types: Ring Main Unit/Radial Supply
Insulation Level (BIL): 30-200 kV
Standards: ANSI/IEEE, CSA/CAN, DOE
Applications: BESS, data centers, industrial, renewable energy, EV charging, utilities
Power Ratings: 1000 kVA, 1 MVA

Nantong Dazheng Electric Co., Ltd. is a professional transformer manufacturer qualified to produce transformers with voltage levels up to 44kV. Annually, we export thousands of these transformers to the USA and Canada. Our team is proficient in IEEE/ANSI, CSA, DOE, NEMA standards, ensuring compliance with various regulatory requirements. With extensive project experience, we understand the unique demands of each project. Hence, we offer customizable transformers, allowing for adjustments in voltage, capacity, connection methods, and special designs to perfectly meet your needs. 1000 kVA pad-mounted transformers can be customized according to your project requirements.
